Agent

The agent runs on each DCV workstation. It manages local Amazon DCV sessions, reports system statistics to the director, and handles certificate lifecycle (auto-registration and renewal).

dcvix Agent

Responsibility

  • Register with the director automatically on first startup (Ed25519 key pair + GUID + CSR)
  • Renew its TLS certificate before expiry (every ~12 hours by default)
  • Create, list, and close local DCV sessions via the dcv CLI
  • Report system stats (memory, CPU, load) and active sessions to the director periodically
  • Clean up stale idle sessions (configurable reaper interval)
  • Serve a REST API for the director to request session operations

Lifecycle

flowchart TD
    A[Start] --> B{agent.crt valid?}
    B -- No --> C[Generate Ed25519 key pair]
    C --> D[Load or generate GUID]
    D --> E[Register loop: POST /v1/agent/register]
    E -- 403 pending --> E
    E -- 200 OK --> F[Store signed cert + CA]
    B -- Yes --> G[Start mTLS server]
    F --> G
    G --> H[Start renewal loop]
    G --> I[Start stats updater]
    G --> J[Start session reaper]

Phases

  1. Key generation - certificate.Manager.EnsureKeyPair() generates Ed25519 key on first run, stores at {dataDir}/agent.key (0600)
  2. GUID generation - EnsureGUID() creates UUIDv4, persists to {dataDir}/agent.guid
  3. Registration - registrator.Registrator.Register() loops every 30s: generates CSR with CN dcvix-agent-{guid}, POSTs TOFU HTTPS to director, waits for admin approval
  4. Active service - starts mTLS server once agent.crt and ca.pem exist, begins renewal + stats + reaper loops
  5. Renewal - renewer.Renewer checks CertificateNeedsRenewal() (24h window), POSTs fresh CSR via mTLS to /v1/agent/renew

Inputs / Outputs

Direction Method Content
Director in POST /v1/sessions Create session (UserID, SessionType, SessionID)
Director in DELETE /v1/sessions/{id} Close session
Director in POST /v1/config Set DCV config parameters
Out to director POST /v1/agent/register CSR + GUID + hostname (plain HTTPS, TOFU)
Out to director POST /v1/agent/renew CSR (mTLS)
Out to director POST /v1/agent/update Sessions list + stats + tags (mTLS, every update_interval)
Out dcv CLI Create/list/close sessions via the system DCV binary

All endpoints except /v1/health require mTLS authentication by the director (validated via director-issued CA).

API Endpoints

Method Endpoint Description
GET /v1/health Health status of the agent
GET /v1/sessions List all active DCV sessions
POST /v1/sessions Create a new DCV session
DELETE /v1/sessions/{id} Close a DCV session
POST /v1/config Set DCV configuration parameters
GET /v1/stats Return session list and system stats for the director

POST /v1/sessions

Request body:

{
    "userId": "USERNAME",
    "sessionType": "console",
    "sessionId": "SESSIONNAME"
}

POST /v1/config

Request body:

{
    "config": [
        {
            "section": "display",
            "key": "quality",
            "value": "(30,80)"
        }
    ]
}

curl Examples

All agent API calls (except /v1/health) require mTLS authentication with director-issued certificates, verified against the director's CA.

Health

curl --cert dcvix-director.crt --key dcvix-director.key --cacert ca-cert.pem \
     https://127.0.0.1:8446/v1/health

List Sessions

curl --cert dcvix-director.crt --key dcvix-director.key --cacert ca-cert.pem \
     https://127.0.0.1:8446/v1/sessions

Create a New Session

curl --cert dcvix-director.crt --key dcvix-director.key --cacert ca-cert.pem \
     -X POST \
     -H "Content-Type: application/json" \
     -d '{"userId": "john", "sessionType": "console", "sessionId": "test"}' \
     https://127.0.0.1:8446/v1/sessions

Close a Session

curl --cert dcvix-director.crt --key dcvix-director.key --cacert ca-cert.pem \
     -X DELETE \
     https://127.0.0.1:8446/v1/sessions/test

Set Compression Quality

curl --cert dcvix-director.crt --key dcvix-director.key --cacert ca-cert.pem \
     -X POST \
     -H "Content-Type: application/json" \
     -d '{"config": [{"section": "display", "key": "quality", "value": "(30,80)"}]}' \
     https://127.0.0.1:8446/v1/config

Internal Packages

Package Role
certificate/ Ed25519 key pair, GUID, CSR generation, cert/CA storage, CertificateNeedsRenewal()
registrator/ Retry loop (30s), TOFU or pre-deployed CA, stores signed cert on success
renewer/ Periodic renewal (configurable, default 12h), retry every 5min on failure
dcv/ Wraps dcv binary: create-session, list-sessions, close-session, set-config
stats/ System statistics collection (memory, CPU, load)
updater/ Periodic POST of sessions + stats to director
reaper/ Cleanup of stale idle sessions (configurable interval, default 60s)
server/ REST API + mTLS with GetCertificate callback for hot-reload
client/ HTTP clients - NewRegistrationClient() (TOFU) and NewMTLSClient() (strict)

Failure Modes

Scenario Behavior
Director unreachable Registration or renewal retries. Cert valid for 14 days - tolerant of extended outages.
Cert expired Falls back to fresh registration (same GUID, same key - re-approval needed).
agent.key lost Generates new key + new GUID on next start. Registers as a completely new agent.
agent.crt lost (key + GUID intact) Re-registers with same GUID. Director sees pending for an already-registered GUID, admin approves.
dcv binary missing or fails Returns error to director on session operations; stats reporting continues unaffected.
data_dir permissions wrong Startup fails if data_dir cannot be created or written to.
